A customer reports that each time a networking component fails, OSPF recalculates the backup path, with causes a short outage. Which solution must the customer implement to improve this situation?
A network engineer must design an MSDP multicast solution to provide RP resilience in a network with two separate domains. Also, multicast sources and receivers must register with the local RP. Which solution must the engineer choose?
Answer : B
Both can be true and correct because if you check the link:
https://www.cisco.com/c/en/us/support/docs/ip/ip-multicast/115011-anycast-pim.html
Relevant running configurations
Nexus 1 relevant configuration:
ip pim rp-address 10.1.1.1 group-list 224.0.0.0/4
ip pim anycast-rp 10.1.1.1 192.168.1.1
ip pim anycast-rp 10.1.1.1 192.168.2.2
interface loopback1
ip address 192.168.1.1/32
ip router ospf 1 area 0.0.0.0
ip pim sparse-mode
interface loopback7
ip address 10.1.1.1/32
ip router ospf 1 area 0.0.0.0
ip pim sparse-mode
interface Ethernet9/2
ip address 10.7.7.1/24
ip router ospf 1 area 0.0.0.0
ip pim sparse-mode
interface Ethernet9/3
ip address 172.16.1.2/24
ip router ospf 1 area 0.0.0.0
ip pim sparse-mode
Refer to the exhibit.
The failover time of ISP-2 is significantly shorter than ISP-1 when an interface on the ISP router toward the campus network fails. Which solution minimizes the downtime to the sub-second?
Refer to the exhibit.
An architect is designing an EIGRP solution based on these requirements:
* Traffic forwarding should use the best two paths while all links are available
* Single path failure must not impact traffic between branch and HQ
Which solution must the architect select?
Answer : D
ENSLD cert guide page 113. shortest path = 900, next 1700 and finally 3300 for the worst path. Witch variance 2, all routes under 1800 (900x2) become active.
Which two overlay network design considerations must be made for a Cisco SD-Access network? (Choose two.)
