Question 1

Which of the following statements are true about the default route?

AIf the destination address of a packet does not match any entry in the routing table, the packet is forwarded through the default route

BIn a routing table, the route to 0.0.0.0 (with the mask being 0.0.0.0) is the default route

CThe routing table of any router must contain the default route

DThe default route can only be manually configured by the administrator

Answer : A, B, D

Question 2

Which of the following statements are true about the dynamic MAC address table?

AAfter a device is reset , an interfaces card is hot swapped , or an interface card is reset , the saved entries on the device or interface card are not lost.

BDynamic MAC address entries are obtained by learning the source MAC addresses of packets received by an interface, and can be aged out.

CAfter a device is rest , an interface card is hot swapped or an interface card is reset dynamic MAC address entries on the device or interface card are lost.

DYou can obtain the number of users communicating on an interface by checking the number of specified dynamic address MAC address entries.

Answer : B, C, D

Question 3

Which of the following statements are true about the static MAC address table?

AAfter a device is reset an interface card is hot swapped or an interface card is reset, the saved entries on the device or interface card are not lost

BAfter an interface is statically bound to a MAC address, other interface discarded a packet whose source MAC address is the bound MAC address

CEach static MAC address entry can be bound only to one outbound interface

DYou can check whether data is forwarded between two connected devices by checking the static MAC address entries

Answer : A, B

Question 4

Which of the following statements is true about direct routes?

AThe priority of the direct route is lower than that of the dynamic route

BThe priority of the direct route is lower than that of the static route

CThe administrator needs to manually configure the destination network and next-hop address for the direct route

DThe direct route has the highest priority

Answer : A, D

Question 5

As Shown in the following figure, the switch configuration information is as follows. Which of the following statement about the network and configuration is/are true?

Router A

aaa

local-user test password cipher test local-user test service-type ppp

interface Serial1/0/0 link-protocol ppp

ppp authentication-mode chap

ppp pap local-user test1 password cipher test1

ip address 10.0.12.1 255.255.255.0

Router B

aaa

local-user test1 password cipher test1 local-user test1 service-type ppp

interface Serial1/0/0 link-protocol ppp

ppp authentication-mode pap

ppp chap user test

ppp chap password cipher test

ip address 10.0.12.12 255.255.255.0

AThe Authentication mode of the interface on Router A is CHAP.

BRouter A uses the user name 'test1' and password 'test1' to pass the interface authentication of Router B

CThe Authentication mode of the interface on Router B is PAP.

DRouter B uses the user name 'test1' and password 'test1' to pass the interface authentication of Router A

Answer : A, B, C
