Question 1

Which of the following statements about a Management VPLS is FALSE?

AOperates in transparent mode.

BCarries RSTP BPDUs only.

CAssigns RSTP state to other VPLS services.

DAllows load balancing among multiple management VPLS instances.

Answer : C

Question 2

According to the SAP-egress policy configured and applied, which queue will EF traffic use?

AQueue 2 in 'policer-output-queues,' the default queue group used by policers on egress, because there are no queues in the 'qg-10' queue-group template.

BThe local SAP's queue 1, because there is no queue in the 'qg-10' queue-group template for EF traffic.

CQueue 1 in the 'qg-10' queue-group, because it exists by default and all traffic is mapped to it.

DEF traffic is dropped because there are no queues in the 'qg-10' queue-group template.

Answer : B

Question 3

By default, how does a hybrid port on a Nokia 7750 SR share its allocated buffer space between access and network pools?

AAll buffer space is initially allocated to access pools, and some of it is reallocated to network pools if network interfaces are configured on it.

BAll buffer space is initially allocated to network pools, and some of it is reallocated to access pools if service SAPs are configured on it.

CBuffer space is allocated 50% for access pools and 50% for network pools.

DBuffer space is allocated 25% for access pools and 75% for network pools.

Answer : B

Question 4

What is the purpose of the Nokia SR design that includes, for every ingress unicast queue, one hardware queue per destination forwarding complex (FFPC)?

ATo utilize memory resources efficiently

BTo avoid Head of Line blocking

CTo achieve more granularity of QoS control

DTo make hierarchical scheduling/policing possible

Answer : B

Question 5

Given the scheduler-policy parameters shown, and assuming the offered rate of each queue is 10 Mbps, what are the operational PIR and CIR for queue 1?

APIR = 4 Mbps, CIR = 1 Mbps

BPIR = 1 Mbps, CIR = 1 Mbps

CPIR = 10 Mbps, CIR = 1 Mbps

DPIR = 5 Mbps, CIR = 5 Mbps

EPIR = 1.25 Mbps, CIR = 1.25 Mbps

Answer : D
